Product Name:

ASUS PRO WS W680-ACE (Socket 1700/C262/DDR5/S-ATA 6Gb/s/Mini ITX)

Web Address:

www.asus.com

Model Number:

P13R-I

EAN:

4711636232623

Package Type:

Retail

Warranty:

3 Years

Core Logic:

Intel C262

CPU Interface:

Socket 1700

CPU Support:

https://servers.asus.com/products/servers/server-motherboards/P13R-I#Resources

Memory Total Slots:

2 (2 Channels)

Memory Capacity:

Maximum up to 64GB

Memory Type:

DDR5 4800/4400/4000/3600 ECC UDIMM

Memory Size:

64GB

Total Expansion Slots:

1

Slot Location 1:

1 x PCI-E x16 (x16 Gen5 Link)

S-ATA Controller:

6 x SATA 6Gb/s ports by 4 Mini-SAS HD connectors

M.2 Connector:

1 x M.2 connector(2280,support NVMe PCIe x4 link)

On-Board LAN:

2 x Intel I210-AT2 + 1 x Mgmt LAN

On-Board Video:

Aspeed AST2600 with 64MB VRAM (VGA from BMC)

Back Panel I/O Ports:

• 2 x USB 3.2 Gen2
• 2 x USB 3.2 Gen1
• 1 x VGA port (VGA from BMC)
• 2 x 1 GbE LAN + 1 x Mgmt LAN

Internal I/O Connectors:

• 1 x VGA Header (VGA from BMC)
• 1 x TPM header
• 1 x COM port
• 2 x Fan Header , 4pin
• 1 x Chassis Intruder
• 2 x Front LAN LED
• 1 x PSU Power Connector (24-pin ATX power connector + 8-pin ATX 12V power connector)
• 1 x M.2 Connector
• 2 x USB 3.2 Gen2 (rear)
• 2 x USB 3.2 Gen1 (rear)

Management Solution:

On-Board ASMB11-iKVM for KVM-over-IP

Environment:

• Operation temperature: 10? - 50?*
• Non operation temperature: -40? - 70?
• Non operation humidity: 20% - 90% ( Non condensing)
• *The boundary condition above is based on 8.3W of PCH TDP spec . If the LFM estimate is higher than acceptable value from customer, ASUS can provide boundary condition with raw power for reference.

Form Factor:

Mini ITX

Product Width:

170mm

Product Length:

170mm

Net Weight:

0.86Kg

Package Width:

28.1cm

Package Length:

34.1cm

Package Height:

7.8cm

Gross Weight:

1.20Kg

Special Features:

• Powered by an 8-core Intel Xeon E-2400 series and Intel Xeon 6300 series processor with support for up to 95 watt TDP.
• Flexible expandability with six native SATA ports and one PCIe 5.0 x16 slot.
• Dual Intel I210-AT2 gigabit Ethernet ports with teaming support.
• One M.2 slot for faster OS booting, and two DDR5 ECC UDIMM slots up to 64 Gbps.
• Onboard ASUS ASMB11-iKVM with ASPEED AST2600 controller for out-of-band management.
• Mini-ITX board in a compact footprint, making it a popular choice for SMB general purpose, mail and storage applications.

Package Contents:

• Motherboard
• Gift Box (1-in-1)
• 1 x I/O shield
• 1 x Plate for LGA1700
• Bulk Pack (10-in-1)
• 1 x I/O shield
• 1 x Plate for LGA1700
