Product Name:

ASUS Pro WS W790E-SAGE SE (Socket AM5/B850/DDR5/S-ATA 6Gb/s/Micro ATX)

Web Address:

www.asus.com

Model Number:

PRO WS B850M-ACE SE

EAN:

4711636258753

Package Type:

Retail

Warranty:

3 Years

BIOS:

• 512 Mb Flash ROM
• UEFI AMI BIOS (text-based)

Chipset:

AMD B850

CPU Interface:

Socket AM5

CPU Support:

https://www.asus.com/motherboards-components/motherboards/workstation/pro-ws-b850m-ace-se/helpdesk_qvl_cpu?model2Name=Pro-WS-B850M-ACE-SE

RAM Technology:

DDR5 (Dual Channel)

RAM Slots:

4 x 288-pin

RAM Speeds:

Up to DDR5 8000 (O.C.)

Max. Memory Support:

256GB

PCI Express 4.0 x16:

1

PCI Express 5.0 x16:

1

S-ATA 6Gb/s Port(s):

4

RAID:

Raid 0/1/5/10

M.2 Socket(s):

2 x PCIe Gen 5.0 x4

On-Board LAN:

• 1 x Realtek 10Gb Ethernet
• 1 x Intel® 2.5Gb Ethernet
• 1 x Realtek 1Gb Ethernet

On-Board Audio:

Realtek 7.1 Surround Sound High Definition Audio CODEC

On-Board Video:

Processor with integrated graphics is required

Back USB 2.0 Port(s):

2

Back USB 10Gbps Port(s) Type-A:

3

Back USB 10Gbps Port(s) Type-C:

2

Back VGA Port(s):

1

Back HDMI Port(s):

1

Back DisplayPort(s):

1

Back LAN Port(s):

3

Back Audio Jack(s):

2

Back Button(s):

1 x Clear CMOS

24-pin ATX Power:

1

8-pin ATX Power:

1

4-pin ATX Power:

1

USB 2.0 Header(s):

1

USB 3.0 Header(s):

3

USB 5Gbps Header(s):

1

USB 20Gbps Header(s):

1

Thunderbolt Header(s):

1

COM Port Header(s):

1

Front Panel Audio Connector:

1

TPM Header(s):

1

Internal Other Port(s):

1 x Thermal Sensor header

Internal Button(s):

• 1 x BIOS FlashBack
• 1 x Reset
• 1 x Start

Form Factor:

Micro ATX

Product Width:

244mm

Product Length:

244mm

Package Width:

28cm

Package Length:

28cm

Package Height:

7cm

Net Weight:

0.96Kg

Gross Weight:

1.04Kg

Special Features:

• Ready for Advanced AI PCs: Built to power next-gen AI workloads with robust performance, ultrafast connectivity, and future-proof architecture.
• AMD AM5 Socket Support: Compatible with AMD Ryzen 9000/8000/7000 Series and AMD EPYC 4005 Series processors.
• Ultrafast Connectivity: Two PCIe 5.0/4.0 x16 slot (one at x4), 10 Gb and 2.5 Gb LAN ports, two PCIe 5.0 x4 M.2 slots, front USB 20Gbps Type-C and MCIO NVMe support.
• Server-grade IPMI Remote Management: Supports onboard BMC AST2600, along with ASUS Control Centre Express IT management software for real-time monitoring and management.
• Proven Reliability and Stability: Extensively validated with broad compatibility, a comprehensive QVL, and tested for 24/7 operation.

Package Contents:

• Motherboard
• 2 x SATA 6Gb/s cables
• 1 x I/O shield
• 1 x Q-connector
• 1 x M.2 rubber package(s)
• 1 x ACC Express activation key card
• 1 x Quick start guide
